IDRA 4

IDRA 4

IDRA 4

IDRA 4 IS A TRAILER-MOUNTED COVERED ASPIRATOR WITH FILTERING SLEEVES

Upon request:

ᐳ 2.2 kW (3 HP) three-phase motor-driven
ᐳ Fan noise: 60 dB (A) (2.300/3.300 m/h)
ᐳ 250 mm adaptor for outlet piping
ᐳ 250 mm galvanised steel outlet piping
ᐳ Ø 160 mm reducing cone for suction hood
ᐳ Ø 160 mm multi-way manifolds
ᐳ Flexible plastic tubing in various diameters

The equipment is fitted for filtered air outlet.

Motor-driven fan can be mounted with upward suction hood.

FEATURES

ᐳ Motor power (three-phase): 2.2 kW (3 HP),
ᐳ 9 filtering sleeves: Ø80x1.030mm,
ᐳ Suction capacity: 2.500/3.500 m3/h,
ᐳ Noise according to ISO 3746-79: mean pressure level 68,4 dB (A),
ᐳ Suction mouth: Ø 160 mm,
ᐳ Net Weight: 165 Kg,
ᐳ Overall dimensions unit ready for use: 730 × 1.500 x 2.670 mm,
ᐳ Overall dimensions disassembled and packed unit: 750x1.350x900mm.
